Lighting setups
with a way back.

Start here when you need a practical arrangement, not a mood board. Every setup names the source, working exposure, result and the one change most likely to move the image.

08repeatable
arrangements

How to use this library Pick the setup closest to your light, make one test frame, then change only one variable. The settings are starting points, not promises.

Read our method
A portrait subject making a half-turn beside a tall window with soft light across the face01

Natural portrait beside a tall north-facing window

North Window Half-Turn

Focal50mmAperturef/2.8Shutter1/160 secISOISO 400
camerasubjectsource

Position. Window 90 degrees camera left, subject 1 m away.

Result. A soft cheek highlight with enough shadow to keep the face dimensional.

Variant. Move the subject 30 cm toward the glass for more contrast; add white card camera right for a gentler fill.

A seated portrait subject lit by one softbox high and camera left in a quiet studio02

Seated portrait with controlled triangular cheek light

Single Softbox Rembrandt

Focal85mmAperturef/4Shutter1/200 secISOISO 100
camerasubjectsource

Position. 90 cm softbox high camera left, angled 35 degrees down.

Result. A calm portrait with shaped shadow and a small triangle of light on the far cheek.

Variant. Raise the source for deeper eye sockets; bring a silver reflector close for a cleaner commercial finish.

A photographer bouncing a compact flash from a white wall during a dim evening reception03

Fast candid coverage in a low-lit room

White-Wall Bounce Reception

Focal35mmAperturef/2.8Shutter1/80 secISOISO 1600
camerasubjectsource

Position. Speedlight aimed at white wall 2 m camera left, TTL starting point.

Result. Readable faces while the room keeps its warm ambient colour and motion.

Variant. Use manual flash for consistency once the distance is stable; turn toward the ceiling for a softer top light.

A tripod-mounted camera facing layered hills with a textured foreground under soft cloud04

Layered landscape with foreground texture and a distant horizon

Overcast Two-Layer Landscape

Focal24mmAperturef/8Shutter1/60 secISOISO 200
camerasubjectsource

Position. Large natural sky as source, tripod low behind foreground texture.

Result. A quiet frame with a tactile near layer, legible middle distance and open sky.

Variant. Lower the tripod for more foreground; wait for a break in cloud to separate the far ridge.

A camera and hand-made object arranged beside a side-lit tabletop with a white card05

Small product or craft detail with a controlled shadow

Tabletop Side Light

Focal70mmAperturef/5.6Shutter1/125 secISOISO 200
camerasubjectsource

Position. Window camera left, white card 30 cm camera right.

Result. Texture remains visible while the side shadow gives the object a sense of weight.

Variant. Pull the card farther away for stronger shape; add black card opposite for a deeper edge.

Two people standing just inside a bright doorway with gentle reflected light on their faces06

Environmental portrait for two people in a bright doorway

Two-Person Doorway

Focal35mmAperturef/4Shutter1/250 secISOISO 320
camerasubjectsource

Position. Open doorway behind camera, shaded wall behind subjects.

Result. Even faces and a little environmental context without the doorway becoming a blown rectangle.

Variant. Turn subjects 20 degrees toward the opening; expose for the faces and let the outside fall bright.

A performer waiting at the edge of a small stage with a soft fill light just out of frame07

Performance portrait with a small soft source

Low-Angle Stage Fill

Focal70mmAperturef/2.8Shutter1/320 secISOISO 1250
camerasubjectsource

Position. Small soft source low camera right, stage light retained as rim.

Result. A face that stays present while the stage colour and direction remain part of the scene.

Variant. Reduce fill for a more dramatic profile; move farther back and use 135mm for a compressed stage layer.

A photographer reviewing contact sheets under a warm desk lamp beside a calibrated monitor08

Quiet editorial portrait of a photographer reviewing work

Desk Lamp Workflow

Focal50mmAperturef/2Shutter1/80 secISOISO 800
camerasubjectsource

Position. Warm desk lamp behind and camera left, monitor fill kept low.

Result. A working atmosphere with visible hands, paper and screen glow without a staged smile.

Variant. Turn off the monitor for a paper-first frame; raise ISO instead of overpowering the room with flash.
